Half pencil marks exact copies

Half pencil marks exact copies
FAMILY HANDYMAN

While trying to trace an exact copy of the throat plate for my table saw, I came up with this nifty technique using an ordinary pencil. I just shaved my pencil into a half-pencil by carefully grinding it on my belt sander. The flat edge enables my modified pencil to ride straight up along the edge of the template. It also works great for marking and then shaping inlays for my woodworking projects. — Tim Reese

Advertisement

Perfect bar clamp cover

Perfect bar clamp cover
FAMILY HANDYMAN

Iron pipe clamps can easily mar softer woods or react with the glue to stain the wood. My solution is to cut a section of plastic PVC pipe to size and place it around the pipe. If you have several short lengths, you can space them strategically to accommodate different widths of stock wood. — Tim Johnson

Here are 19 practical woodworking projects for beginners.

Quick blade-height gauge

Quick blade-height gauge
FAMILY HANDYMAN

This gauge block is the quickest way to set the height of a table saw blade. This one is made from a 8cm length of 4×4 cut to the settings used most frequently. If you need more settings, just create another block.

Then when it’s time to reset the table saw blade, these blocks will help you get the job done quickly.

DIY Basics: Don’t miss our essential guide to stationary power saws.

Flexible sanding block from the office

Flexible sanding block from the office
FAMILY HANDYMAN

Sanding curves is tricky. Sometimes you need a sanding pad that’s both firm and flexible. A small notepad works great. Just wrap sandpaper around the pad and bend the pad to whatever arc you need. Slip the one end of the sandpaper between the pages to help hold it in place on the pad. Give this a try the next time you’re working on a project that has curves and tough to reach spots.

Here are more ghenius sanding tips you need to know.

Cheap stain sprayer

Cheap stain sprayer
FAMILY HANDYMAN

Here’s an easier way to stain or seal chairs, lattice or anything with numerous tight recesses. Pour the stain into a clean, empty spray bottle. Spray the stain onto the project and wipe up the excess with a brush or rag. The sprayer will squirt stain into all those tight, hard-to-reach cracks and joints. — Valrie Schuster

Never-fail mitre joint clamp

Never-fail mitre joint clamp
FAMILY HANDYMAN

Clamping up four mitred corners is tricky. You can buy specialty clamps for this, but I make my own. Here’s how to do it: Start with a long 1×4, as it’s easier (and safer) to clamp for making the angled cuts than a short piece. Mark out the blocks, and then drill a 2cm diameter hole in the centre of each one. The hole prevents the blocks from getting glued to your project. Cut 45-degree angles tangent to the hole, and then cut the blocks free from the long board.

Check out our tips for tigher mitres.

Slick table saw tip

Slick table saw tip
FAMILY HANDYMAN

I find the best way to protect my cast-iron table saw top is to occasionally rub on a coat of paste wax. This gives me a nice, slick top for easier material feeding, and if I drip glue on the surface, it won’t stick. It also helps prevent surface rust when the air is humid. — Jack Linden

Safety when cutting small parts

Safety when cutting small parts
FAMILY HANDYMAN

Recently I needed to cut some small furniture legs on my mitre saw. With their irregular shape, they were impossible to hold safely, so I attached each leg to a scrap 2×2 with a dowel screw. These assemblies stayed straight and kept my hands far from the blade. — David Alexander

Improvised t-bevel

Improvised t-bevel
FAMILY HANDYMAN

Not long ago, I needed to make some angled wood parts to build a new soffit on my garage. I didn’t have the customary tool for the job, but I had some steel joining plates. I screwed through one of the holes in the plate, set my angle, then added another screw to lock the angle. I could then use it as a template to mark all the pieces at the same angle and cut them with my circular saw. — Ryan Bartsch

Here are 10 woodworking joints you should know.

Bi-fold workbench

Bi-fold workbench
FAMILY HANDYMAN

Old doors laid across sawhorses make great temporary workbenches, but they take up a lot of space when you’re not using them. Instead of full-size doors, I use bifold doors with hinges so I can fold them up when I’m done working. They’re also easier to haul around in the pickup for on-the-road jobs. — Harry Steele
